Model | GM-1200P | GM-1600P | GM-2000P | GM-3000P |
Pressing capacity | 10 ton | 14 ton | 16 ton | 25 ton |
Motor power | 1.1KW | 1.5KW | 2.2KW | 3.0KW |
Bolster size | 410×250mm | 490×310mm | 530×320mm | 660×400mm |
Die height maximum | 150mm | 195mm | 210mm | 210mm |
Slide stroke | 44mm | 50mm | 57mm | 80mm |
Slide bottom size | 127×135mm | 142×150mm | 162×150mm | 195×200mm |
Hole size | 25.4mm | 31.75mm | 38.1mm | 40mm |
Working speed | 100-180 | 100-150 | 100-120 | 100 |
Net weight | 470KG | 800KG | 1000KG | 1500KG |
Dimension (mm) | 850×800×1850 | 900×850×2100 | 950×900×2300 | 1200×1100×2100 |
Packing dimension (mm) | 1100×1050×2050 | 1150×1100×2350 | 1300×1150×2550 | 1500×1400×2400 |
Electric voltage | 380V, 3 phase, 50HZ |
