0.5-3.0mm, cradle model CL

  • 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400
  • 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400
  • 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400
  • 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400
  • 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400
0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400 0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400

0.5-3.0mm cradle type decoiler and straightener 2 in 1, model CL-150, 200, 300, 400

  • Brand： GOODMAC
  • Model： CL-150, CL-200, CL-300, CL-400
  • Decoiler power： without motor motive
  • Coil car for coil： no
  • Coil inside diameter ： 50-530 mm
  • Pressing arm for coil： no
  • Coil retainer： standard
  • Straightening roller adjustment method： by hand wheel and spring
  • Variable frequency speed control system： optional
  • Loop control： electronic touch sensor
  • INQUIRY

This series machine contains decoiler and straightener together, so as 2 in 1.
It can decoil sheet metal strip coil, then straighten it automatically, for automatic stamping & punching.
It has perfect straightening performance.
It can be customized according to your special application requirement. Welcome to contact us for more details.

Specification

ModelCL-150CL-200CL-300CL-400
Metal sheet coil width150mm200mm300mm400mm
Metal sheet thickness0.5-3.0mm
Coil inside diameter50-530mm
Coil outside diameter maximum   1000mm
Coil weight400KGS500KGS500KGS500KGS
Straightening speed15m/min
Inverter for adjusting speedoptional
Motor power1HP2HP3HP
Net weight350KGS400KGS450KGS500KGS
Machine size (m)1.6×0.6×1.41.6×0.7×1.41.7×0.8×1.41.8×0.9×1.5
Straightening roller7 pieces
Roller pressure adjustingby hand wheel
Electrical power380V, 3 phase, 50HZ
