YANGLI press machine

  • YANGLI 400ton H frame two crank press machine, model JM36-400
  • YANGLI 400ton H frame two crank press machine, model JM36-400
  • YANGLI 400ton H frame two crank press machine, model JM36-400
YANGLI 400ton H frame two crank press machine, model JM36-400 YANGLI 400ton H frame two crank press machine, model JM36-400 YANGLI 400ton H frame two crank press machine, model JM36-400

YANGLI 400ton H frame two crank press machine, model JM36-400


YANGLI 400ton H frame two crank press machine, model JM36-400
Pressing capacity: 400ton
Nominal stroke: 10mm
Stroke: 280mm
Stroke speed: 18-25 SPM
Die height: 650mm
Slide adjustment: 120mm
Bolster area(F
·B×L·R): 1100×2500mm
Bolster thickness: 200mm
Slide area(F
·B×L·R): 1000×2300mm
Shank hole(diameter
×depth): 3-70×95mm
Distance between columns: 2700mm
Side opening(F
·B×H): 1020×650mm
Bolster height: 1200mm
Main motor power: 45KW
Outline dimension(F
·B×L·R×H): 3700×3650*4900mm
Net weight: 52000KG
