NC servo roll feeders, model RNC

  • 0.2-1.6mm NC servo roll feeders, model RNC-200M, 300M, 400M (mechanical releasing)
  • 0.2-1.6mm NC servo roll feeders, model RNC-200M, 300M, 400M (mechanical releasing)
0.2-1.6mm NC servo roll feeders, model RNC-200M, 300M, 400M (mechanical releasing) 0.2-1.6mm NC servo roll feeders, model RNC-200M, 300M, 400M (mechanical releasing)

0.2-1.6mm NC servo roll feeders, model RNC-200M, 300M, 400M (mechanical releasing)


Specification

ModelRNC-200MRNC-300MRNC-400M
Metal sheet width200mm300mm400mm
Metal sheet thickness0.2-1.6mm
Feeding roller2 pieces
Feeding length per stroke 0.1-9999.99 mm
Feeding length accuracy±0.1mm
Feeding speed0-24m/min
Roller releasing methodby mechanical rod (for high speed)
Servo motor and driveYASKAWA (JAPAN brand)
PLCMITSUBISHI (JAPAN brand)
Human machine interface (HMI)WEINVIEW (Taiwan brand)
Other main componentsother brands
Motor power0.75KW1.0KW1.0KW
Electrical power380V, 3 Phase, 50HZ (or else)
